FULTON VSRT 50 - Page 71

MAINTENANCE & TROUBLESHOOTING  4
Questions? Call (315) 298-5121, or visit us online at www.fulton.com
4-11
VSRT_IOM_2018-1213
VIEW26
BILL OF MATERIAL
U.O.M.QTYDESCRIPTION
PART NUMBERITEM
EA.1
3/4" NPT SIGHT OBSERVATION PORT
2-12-000012
1
EA.1
029 1/16" VITON O-RING 1.625 OD
2-12-0007212
EA.
1
VSRT PV FLANGE TO TOP PLATE GASKET FOR 10" FURNACE
2-12-2900143
EA.1
VSRT 140MM BURNER GASKET2-12-290015
4
EA.
2
5" ID X 6" LG. NITRILE FLEX COUPLING
2-12-290036
5
EA.1
10-24 X 1/2" UNC HEX HEAD SELF TAPPING SCREW
2-22-0000339
EA.
6
1/2" USS FLAT WASHER
2-22-000042
7
EA.
6
1/2-13 HEX NUT, GR. 2H
2-22-0000588
EA.
6
1/2" MEDIUM LOCK WASHER
2-22-0000599
EA.4
3/8-16 NiCu400 HEX NUT (MONEL400)
2-22-00015610
EA.
2
1/4" 316 STAINLESS STEEL LOCK WASHER
2-22-000268
11
EA.4
IDEAL 5.25" - 5.56" ID SS T-BOLT BAND CLAMP - 30010-0525
2-22-00043112
EA.4
3/8" 316 STAINLESS STEEL LOCK WASHER
2-22-00046113
EA.
2
1/4-20 x 1" A286 SOCKET HEAD CAP SCREW
2-22-290000
14
EA.1
1/4" FNPT X 1/4" MNPT BALL VALVE CSA
2-30-000282
15
EA.1
DUNGS PRESSURE SWITCH .16" - 1.2" WC (GAO-A4-4-2)
2-30-00509816
EA.
1
WORGAS PREMIX BURNER 140MM OD (PX.1803)
2-30-290300
17
EA.1
1/4" THREADED TEE
2-35-00020418
EA.1
1/4" 3000# PLUG
2-35-00030619
EA.
2
1/4" X 1 1/2" - NPT SCH 80 NIPPLE
2-35-00039420
EA.
1
3/4" X 1-1/2" - NPT STAINLESS STEEL SCH 40 ( 316L ) NIPPLE
2-35-00117821
EA.1
3/4" - 14 NPSM THERMAL BARRIER FOR FLAME DETECTOR
2-40-00046422
EA.1
SIEMENS LMV2-3 HIGH SENSITIVITY UV SCANNER2-40-00110723
EA.
1
VSRT TOP PLATE ASSEMBLY5-10-29000624
EA.1
VSRT PREMIX ELBOW - BURNER SIDE ELBOW ASSEMBLY5-10-29001825
EA.1
VSRT-30 - PREMIX ELBOW WITH PRESSURE SWITCH COUPLING5-10-29002126
EA.1
VSRT PILOT ASSEMBLY (19 3/8" LONG)
7-20-29003027
19
15
18
20
16
20
26
12
12
5
5
12
12
25
27
11
14
2
23
22 21
1
7
9
8
13
10
3
17
4
7
9
8
