FULTON VSRT 50 - Page 75

MAINTENANCE & TROUBLESHOOTING  4
Questions? Call (315) 298-5121, or visit us online at www.fulton.com
4-15
VSRT_IOM_2018-1213
AIR INLET DETAIL
BILL OF MATERIAL
U.O.M.QTYDESCRIPTION
PART NUMBERITEM
EA.1
VSRT BLOWER INLET GASKET2-12-2900102
EA.
8
3/8-16 HEX NUT, GR. 5
2-22-0000036
EA.
8
3/8" USS FLAT WASHER
2-22-000041
11
EA.
8
3/8" MEDIUM LOCK WASHER
2-22-00004712
EA.
8
3/8-16 X 1 1/4" HHCS, SAE GR. 5 BOLT
2-22-00019913
EA.1
1/8" 3000# PLUG
2-35-00024918
EA.1
SQM33 TO 4" FULL PORT BUTTERFLY VALVE - VA33-NF-400
2-40-00109620
EA.1
VSRT 4" AIR INLET
5-05-29003524
EA.1
VSRT-30 4" AIR INLET ASSEMBLY W/ 1-1/4" GAS CONNECTION
5-10-29002229
20
BUTTERFLY VALVE TO BE
PARALLEL TO FLOOR
FACING AWAY FROM BOILER
APPLY LOCTITE 592
29
2
13
11
126
24 18
TORQUE TO 23 FT-LBS
IN STAR PATTERN AS DETAILED ABOVE
(TYP. 8 PLCS.)
1
2
3
4
5
6
78
