TRT800 / P/N 800ATC-(200)-(200)
Operation and Installation
15Document-No: 03.2102.010.71e / Revision: 2.02
3 INSTALLATION
3.1 Notes
The following suggestions should be considered before installing.
The assigned installation company will supply wiring. For diagrams refer
to 3.7 Wiring.
Transponder, External Memory, all cables and antennas shall be
installed according to „FAA AC-143.13-2A Acceptable Methods,
Techniques and Practices – Aircraft Alterations“ and the appropriate
manufacturer’s instructions.
3.2 Telecommunication data
Depending on your national telecommunications legislation, the following
data may be required when applying for the aircraft radio station license:
Manufacturer: Funkwerk Avionics GmbH
Type Designation: TRT800
EASA Number: EASA.21O.045
Transmitter Power Output
71 W
Frequency: 1090 MHz
Emission Designator: 12M0M1D
3.3 Scope of Delivery
Part Number Description
TRT800 Transponder TRT800
TRT800EM External Memory (AC-Address-Adaptor with
wiring)
M4X8ZSW
(3 pieces)
screw for panels up to 5 mm thickness
56S101A4 TNC antenna connector
03.2102.010.71e Manual „Operation and Installation“
EASA Form 1
To Next Page
