Funkwerk TRT800 User Manual

TRT800 / P/N 800ATC-(200)-(200)
Operation and Installation
24 Document-No: 03.2102.010.71e / Revision: 2.02
3.12 Drawings
3.12.1 Dimensions
20mm
15 mm
170 mm
TRT800
TRT800H
65 mm
65 mm
Ø 57 mm
Static Air
Antenna
Power/RS232
3.12.2 Mounting Advices
Connections Area
≈
80 mm
Panel Cut-out
47,0 mm
47,0 mm
57,5 mm
4 x Ø 4 mm
Ø
Connector (plug) has to be clamped with both spring locks
Fixing clips (spring)
left / ri
g
ht
