TRT800 / P/N 800ATC-(200)-(200)
Operation and Installation
28 Document-No: 03.2102.010.71e / Revision: 2.02
4.1.7 Serielle Schnittstelle (RS232)
With the additionally available address adaptor TRT800EMSS the
RS232 interface can be connected to a GPS receiver, to support the
ADS-B Out functionality (Broadcasting of own position which could be
received by other appropriately equipped aircrafts and processed for
collision avoidance)
Selectable Options (How to proceed, see 4.2 Configuration):
• GPS-Receiver for ADS-B out
o FREEFLIGHT (GPS / WAAS Sensor 1201, 19200 Bd)
setting of the GPS receiver: not required.
o NexNav NNL 3101
setting of the GPS receiver: not required
o KLN94 (Bendix King, KLN 89B, KLN 94, KMD 150, 9600 Bd)
setting of KLN89B/KLN94: “Standard RS232 Sentence”
setting of KMD 150: “Type 1 Sentence”
o NMEA-Format (4800 Bd)
setting: data format RMC is expected; to minimize the
amount of data other sub-formats are to be avoided.
• Comm-A/B-support (38400 Bd)
Data format for special purpose. An additional data link processor
allows COMM-A/B operation and processing of the position
information of a flight management system simultanously.
Setting for all described GPS-systems:
1 .. 2 messages per 2 secs.
Information regarding Comm-
/B support as to usability of
other GPS equipment are available from Funkwerk Avionics
GmbH.
