TRT800 / P/N 800ATC-(200)-(200)
Operation and Installation
20 Document-No: 03.2102.010.71e / Revision: 2.02
3.7.3 TRT800EMSS – External Memory (with RS232)
*
Ground Switch/
FLY-GND
If a ground switch is connected, in “on-ground“
state pin 15 must be connected to „GND“,
otherwise leave Pin 15 open.
**
Refer to 3.6.1.3 Background Illumination
**
*
To Next Page
