TRT800 / P/N 800ATC-(200)-(200)
Operation and Installation
5Document-No: 03.2102.010.71e / Revision: 2.02
1 GENERAL
This manual contains information about the physical, mechanical and
electrical characteristics and about installation and operation of the
Mode S Transponder TRT800.
1.1 Symbols
Advices whose non-observance can cause radiation
damage to the human body or ignition of combustible
materials
Advices whose non-observance can cause damage to the
device or other parts of the equipment.
Supplementary information
1.2 Abbreviations
Abb. Meaning Explanation
FID Flight ID Flight plan number or if not assigned
registration number of aircraft
SPI Special Position
Identification
Activation on request by controlers
„Squawk Ident“, transmits SPI Pulse
for 18 seconds, which highlights the
respective traffic item on the
controllers radar screen
AA Aircraft Address assigned ICAO 24 bit Adresse
AC Aircraft Category Defines aircraft type into specific
categorys
RI Reply Information Maximum airspeed
