TRT800 / P/N 800ATC-(200)-(200)
Operation and Installation
33Document-No: 03.2102.010.71e / Revision: 2.02
20 Test-Mode
• leave the test mode with
40 display error logging
press
to return to STBY
47 enter ICAO-24bit Aircraft Address / Aircraft Category (AC) /
Flight-ID (FID)
• the
button shifts the Cursor („^“) one digit to the
right, the
button shifts it one digit to the left
• turn rotary knob to select characters
• press
to enter the next menu item
changes are kept in memory, but are not yet active
• press
to return to the previous menu item
Ground-Switch-Info
• turn rotary knob to select option (Yes/No)
• press
to enter the next menu item
changes are kept in memory, but are not yet active
• press
to return to the previous menu item
Speed Category
• with respect to the maximum airspeed of the aircraft
enter the corresponding value (see 4.1.6) with the rotary
knob
• press to enter the next menu item
changes are kept in memory, but are not yet active
• press to return to the previous menu item
configure RS232 interface (refer to section 4.1.7)
• turn rotary knob to select option
• press
to save and to return to STBY
• Transmission of position data is indicated by “p“ (type of
squitter) in the upper line in the test mode
Turn power off and on with again to activate new
settings.
