TRT800 / P/N 800ATC-(200)-(200)
Operation and Installation
35Document-No: 03.2102.010.71e / Revision: 2.02
Receiver Characteristics:
Sensitivity
RF input power level resulting in a 90 %
reply rate:
A. MTL for ATCRBS and ATCRBS/Mode S
All-Call interrogations: -74 dBm ±3 dB.
B. MTL for Mode S interrogations:
-74 dBm ± 3 dB.
Reply transmission
frequency
1090 ± 1 MHz
RF Peak Power Output
≥ 18,5 dBW (71 W) at antenna base
(with maximum cable attenuation of 1,5 dB)
Squitter (ADS-B) transmitted at random intervals uniformly
distributed over the range from 0.8 to 1.2
seconds, full self-verification of data and
occurrence
Mode S Elementary Surveillance
ICAO 24-bit Aircraft
Address (Hex-Code)
aircraft address as assigned by national
aviation authority
FID Flight ID: Flight Plan call sign or aircraft
registration marking
Capability Report Reports the available data and means by
which the transponder can report.
Pressure Altitude Up to 15 000 ft in 25 ft increments
Flight Status in-flight / on-ground
Mode S Enhanced Surveillance
Level 2es Comm-A / Comm-B: 56/112-Bit-Messages
SI-capability
