4.2 Settings for Analog port: TEL/FAX
4-8
2. Select the terminal connected to “TEL 1-4” from among the pull down menu for
“Type.”
x Telephone : Service type: calls will be made via 4k AMBE
x FAX : Service type: calls will be made via 3.1k Audio
x Telephone and FAX : Service type: Telephone and FAX acknowledged
automatically
Reference)
When you wish to make calls via a different service type, make a call by adding the
service code at the beginning of the calling number.
- When a call is made via 4k AMBE, attach “1*”: “1* 0081 78 631 xxxx”
- When a call is made via 3.1k Audio, attach “2*”: “2* 0081 78 631 xxxx”
- Not attached: A call is made by the service type
** According with “Type” in Analog ports setting
3. Set the extension number in the “Number (1000-9999)” field. Any number from 1000
to 9999 is acceptable, however it is recommended that you allocate the numbers by
categorizing them in groups such as 2000s or 3000s, so that you can identify that the
number belongs to an analog device.
4. “Note” is for note taking. You can enter the installed location of the analog terminal
such as “WH” or “CCR.”
5. When you have completed the setting, click Apply. The message “Setting completed”
will be displayed.
Reference)
The analog terminal which has had its settings made will be reflected upon the
following screens.
x Settings -> PBX settings -> Extension
If you click Edit on the screen, you will be able to edit the registered data.
x Settings -> PBX settings -> Call limit
You will be able to limit making / receiving calls.
x Settings -> PBX settings -> Group
You can make group settings for calling extension numbers.
x Settings -> PBX settings -> Incoming routing
You can make the settings for the call receiving order.
To Next Page
