9.1 Communication Unit: FB-2000
9-4
Fig. 9.1.7 Attachment board removed -1
Fig. 9.1.8 Attachment board removed –2
HUB
(16P0273)
IF
(16P0275)
IF
(16P0275)
HUB
(16P0273)
