9.1 Communication Unit: FB-2000
9-6
Fig. 9.1.11 HUB (16P0272) side A
Fig. 9.1.12 IF (16P0275) side A
Fig. 9.1.13 IF (16P0275) side B
S4: All OFF
TEL1: SLIC + RINGER
TEL2: SLIC + RINGER
TEL3: SLIC + RINGER
TEL4: SLIC + RINGER
Note) As for each
LED, refer to
10-39
