9.4 Antenna Unit: FB-1500
9-16
Fig. 9.4.8 Attaching the radome dropout
prevention rope
Fig. 9.4.9 Attaching the dropout
prevention rope to the radome
Fig. 9.4.7 Carabiner for attaching dropout
prevention rope
Fig. 9.4.6 Radome Dropout
prevention Rope
Fix metal fitting with a thumbscrew.
Fix eyebolt with butterfly nut
