1.1 System Configuration
1-2
Table 1.1.2 Architecture of options for FELCOM-250/500
Name Model Code number Notes
Incoming indicator FB-3000 -
Engineering work material
CP16-04001 attached
Telephone
equipment
FC755D1 -
Engineering work material
CP16-00511 and 00512 attached
Fax FAX-2810 -
Engineering work material
CP16-03510 attached
Transformer OP16-25 004-446-850
Transformer TSU-N05E +cable
for FAX-2820
Drum unit DR-20J 000-170-982-10 For FAX-2820
Toner cartridge TN-25J 000-170-983-10
For FAX-2820
AC-DC power
supply
PR-240 -
Handset FB-8000 -
Engineering work material
CP16-03901 attached
Coaxial cable 12D-SFA-CV 000-136-423-11 Antenna cable – 100 m
CP16-04121 001-067-300
Connector N-SP-12DSFA-CF for
cable 12D-SFA-CV
Installation
Material
CP16-04131 001-067-310
Connector N-P-18U-CF (2 pcs)
for RG-18
Connector CP03-28901 008-542-460
Modular connector for LAN cabled: 2
of MPS588-C
MOD-Z072-020+ 000-167-175-10
2 m, with modular plugs on both
ends
MOD-Z072-050+ 000-167-176-10
5 m, with modular plugs on both
ends
MOD-Z072-100+ 000-167-177-10
10 m, with modular plugs on both
ends
FR-FTPC-CY*10m* 000-147-472-10
With metal wire braid, 10m, no plug
attached
FR-FTPC-CY*20m* 000-147-473-10
With metal wire braid, 20 m, no plug
attached
FR-FTPC-CY *30m* 000-147-474-10
With metal wire braid, 30 m, no plug
attached
FR-FTPC-CY *50m* 000-153-326-10
With metal wire braid, 50 m, no plug
attached
LAN cable
FR-FTPC-CY *100m* 000-153-327-10
With metal wire braid, 100 m, no plu
attached
Modular jack set OP16-13 000-043-228 MJ-2S, 3 m cord, lug
Modular jack box OP16-8 000-043-272 MJ-2S, lug
Joint box TL-CAT-012 000-167-140-10 LAN cable for extension
Cable assembly 81-521-1204-010 000-127-108-11
5 m cable with D-sub 9P on both
ends
Incoming indicator KK-893-3977 000-148-478 For analog telephone
OP16-10 000-043-278 Box-type
Modular jack box
OP16-11 000-043-279
Flush mount type
Antenna unit FB-1500-B - No attachment
Note) The FELCOM-500 Antenna units with no attachments are FB-1500-B
(000-015-767)
To Next Page
