Furuno NAVpilot-711C Installation Manual

v
Optional supply
Name Type Code No. Remarks
Control Unit FAP-7001 - Max. 5 optional units
FAP-7011 - Max. 5 optional units
FAP-7021 - Max. 2 optional units
FAP-7011C - Max. 5 optional units
Remote
Controller
FAP-5551 - Dial type, w/connector
FAP-5552 - Dial type, no connector
FAP-6211 - Button type, w/connector
FAP-6212 - Button type, no connector
FAP-6221 - Lever type, w/connector and
w/CP64-01100
FAP-6222 - Lever type, no connector,
w/CP64-01100
FAP-6231 - Dodge type, w/connector
FAP-6232 - Dodge type, no connector
VOLVO
Interface Kit
FAP-6300 000-022-971 For the IPS drive equipped
vessel
IPS Inter-
face unit
IF-700IPS 000-022-972
VOLVO IPS
Gateway
AUTOPILOT-GATEWAY 000-022-974
Distributor FAP-6800 000-090-242 For connection of three remote
controllers
Terminator BD-07AFFM-LR7001 001-081-140-10
Cable Assy MJ-A10SPF0001-060+ 001-081-150-10 For Distributor Unit, 6 m
MJ-A10SPF0001-120+ 001-081-160-10 For Distributor Unit, 12 m
BD-07AFFM-LR-100 001-081-170-10 For Control Unit, 10 m,
connector at one end
BD-07AFFM-LR-150 001-081-180-10 For Control Unit, 15 m,
connector at one end
BD-07AFFM-LR-200 001-081-190-10 For Control Unit, 20 m,
connector at one end
BD-07AF-07AF-LR-100 001-081-200-10 For Control Unit, 10 m,
connector at both ends
BD-07AF-07AF-LR-200 001-081-210-10 For Control Unit, 20 m,
connector at both ends
M12-05BFFM-010 000-167-965-10 CAN bus drop cable, 1 m,
micro
M12-05BFFM-020 000-167-966-10 CAN bus drop cable, 2 m,
micro
M12-05BFFM-060 000-167-967-10 CAN bus drop cable, 6 m,
micro
CB-05BFFM-010 000-167-971-10 CAN bus drop cable, 1 m, mini
CB-05BFFM-020 000-167-972-10 CAN bus drop cable, 2 m, mini
CB-05BFFM-060 000-167-973-10 CAN bus drop cable, 6 m, mini
T-type
Connector
SS-050505-FMF-TS001 000-168-603-10 For CAN bus, micro+micro
NC-050505-FMF-TS001 000-160-507-10 For CAN bus, mini+micro
