Furuno NAVpilot-711C Installation Manual

3. INITIAL SETTINGS
3-35
3.15 FISH HUNTER OPTION Menu or WIND OPTION
Menu
Depending on the setting for [SHIP’S CHARACTERISTICS], the [FISH HUNTER OP-
TION] menu or the [WIND OPTION] menu follows the [NAV OPTION] menu.
3.15.1 FISH HUNTER OPTION menu
The [FISH HUNTER OPTION] menu lets you preset the parameters for the various turns,
which you access with the TURN key (NAVpilot-700) or TURN/MENU key (NAVpilot-711/
720).
Note: The [FISH HUNTER OPTION] menu is not shown in case of Fantum Feedback
TM
.
CIRCLE
RATE OF TURN: 3 °/s
ORBIT
RADIUS: 0.05 nm
SPIRAL
SPEED: 0.5 kn
RADIUS: 0.05nm
FIGURE 8
RADIUS: 0.05 nm
SQUARE TURN
SIDE LENGTH: 1.0 nm
AZIMUTH: AUTO
ZIGZAG
TURN ANGLE: 90 °
TERMINATION:
CONTINUOUS
DISTANCE:
NUMBER OF TURNS:
WIDTH: 0.5nm
DISTANCE
CONTINUOUS
NUMBER OF TURNS
MANUAL
AUTO
FISH HUNTER OPTION
CIRCLE
ORBIT
SPIRAL
FIGURE 8
SQUARE TURN
ZIGZAG
1
Setting range depends on units
selected on the [UNIT SETUP] menu.
CIRCLE
1
° - 5°/s
ORBIT
SPIRAL
Radius: 0.05 - 9.99nm
FIGURE 8
SQUARE
TURN
Side Length: 1.0 - 9.9nm
Azimuth: 0 - 359
° (Manual)
ZIGZAG
Turn Angle: 30
° - 150°
Number of Turns: 1 - 20
Distance: 1 - 99nm
Width: 0.1 - 9.9nm
Speed: 0.1 - 2.0kn
0.05 - 9.99nm
0.05 - 9.99nm
Set at menu item NUMBER OF TURNS.
Set at menu item DISTANCE.
Item Setting range
1
