FUTABA 2HR - Changing the Neutral Position

27
2HR Functions
ChangingtheNeutralPosition
Change the neutral position only when large forward stroke of the throttle stick is need
when using an FET E.S.C., etc.
(The neutral position is set to the center at the factory.)
*
However, when returning from the 2:1 to the 1:1 position (neutral center),
return the setting lever to the 1:1 side with the stick lever pushed to the HI
side. Other-wise, the setting lever cannot move.
2:1
1:1
Throttle
Stick
SettingLever
1:1 2:1
①
Remove the four transmitter
rear case screws and
remove the front case.
②
Move the setting lever at
the throttle stick body to the
outside.
③
Throttle stick setting lever is
changed.
④
Close the front case while
being careful that the stick
levers, trim levers, power
switch, LEDs, and battery
contacts do not get caught.
And tighten the four screws.
