Before Operation
BeforeOperation
SystemContents
After opening the container, check the contents for the following items. The contents will
vary with the system purchased.
2HR-2.4GHz System Contents
Transmitter
T2HR-2.4G (x1)
Receiver
R202GF (x1)
Servo
----- S3003 (x2) S3003 (x1) S3003 (x1)
E.S.C.
----- ----- MC231CR (x1) MC331CR (x1)
Switch
SSW-GS (x1) ----- -----
Miscellaneous
Mini Screwdriver
*Servo mounting hardware and servo horns (only w/servo set)
Connectors
"B": Power connector
"2" : Throttle Servo (CH2)
"1" : Steering Servo (CH1)
Link SwitchLED
Servo Horn
Mounting
Flange
NOTE: Futaba FHSS system, T2HR-2.4G transmitter and R202GF receiver, does not
work with current Futaba FASST/FASSTest/T-FHSS systems. Please use T2HR-2.4G
and R202GF in pairs. Futaba FASST/FASSTest/T-FHSS system and FHSS system
are not compatible each other.
ReceiverR202GF
ServoS3003
