2HR Functions
ModifyingtheThrottleSticktoaRatchetType
Open the transmitter front case and modify the stick section.
*
7KHUDWFKHWSODWHVROGVHSDUDWHO\LVQHFHVVDU\IRUWKLVPRGL¿FDWLRQ
Selfneutraltype
（Normal）
Ratchettype
Spring
RatchetPlate
Screw
SwingArm
④
Install the
ratchet plate
with the screw.
③
Remove the
spring and
swing arm.
Athrottlestickreturns
neutrallybyaspring.
Athrottlestick
doesn'treturn
neutrally.
Throttle
Stick
①
Remove the four transmitter
rear case screws and
remove the front case.
②
Move the setting lever at
the throttle stick body to the
outside.
⑤
Close the front case while being careful
that the stick levers, trim levers, power
switch, LEDs, and battery contacts do
not get caught. And tighten the four
screws.
