49
＜
Model Basic Setting Procedure
＞
Operation of the swash plate near the hovering
and elevator operation causes the swash plate to
deviate from the normal direction.
Pitch slow side and high side linkage correction is
the swash plate to move up and down in the
horizontal state.
5. Throttle curve setting
This function adjusts the pitch operation curve in relation to
the movement of the throttle stick for each condition.
(17 points curve)
The pitch curve can be freely selected from linear operation
curve to smooth curve, and adjusted to match the curve you
want by means of the T32MZ’s powerful Curve Edit Function
(Six types of curves can be selected). Up to 17 points can be set
for linear or curve types. However, when using the 3 points or 5
be created by selecting the curve type and reducing the number
the corresponding points that you created.
Call the throttle curve of each condition with the condition
select switch.
Normal curve uses Normal (Linear) type and creates
a basic pitch curve centered near hovering. This
(Normal) so that the engine speed is constant and
The high side pitch curve sets the maximum pitch
regardless of the engine load. The low side pitch
curve creates a curve matched for aerobatics
(loop, roll, 3D, etc.).
reset.
The throttle hold curve is used when performing
auto rotation dives.
4. Helicopter linkage
Connect the throttle rudder, ailerons, elevators, pitch, and
other rudder linkages in accordance with the kit instruction
manual. For a description of the connection method, see
"Receiver and servos connection".
*The channel assignment of the T32MZ is different from
that of our existing systems. (The channel assigned to each
function can be checked at the function menu of the Linkage
Menu.)
side function)
the trim setting all the way down.
function and End Point function (rudder angle
can also be set with the End Point function.
