ELEV-FLAP mixing (ACRO/GLID):
ELEV-FLAP mixing is the first pre-programmed mix weíll cover. This mixmakes the
flaps drop or rise whenever the E
LEVATOR STICK is moved. It is most commonly used
to maketighter pylon turns or squarer corners in maneuvers. In most cases, the flaps
droop (are lowered) when up elevator is commanded.
Adjustability:
•Rate: -100% (full up flap) to +100 (full down flap), with a default of +50% (one-half of the flap range is achieved
when the E
LEVATOR STICK is pulled to provide full up elevator.)
•Switch: fully assignable. IF you set it to NULL, the mix does not work.
GOAL of EXAMPLE: STEPS: INPUTS:
55
Activate ELEV-FLAP mixing. Adjust
flap travel to 0% flaps with negative
elevator (push) and 45% flaps with
positive elevator.
Where next?
Open the ELEV-FLAP function.
Activate the function.
Adjust the travels as needed. (Ex: 0%,
to 45%.)
Close menu.
for 1 second.
(If basic,again.)
to ELEV-FLAP.
E
LEVATOR STICK.to0%.
E
LEVATOR STICK.to45%.
Adjust flaperons' flap travel available (FLAPERON): see p. 45.
Set up AIRBRAKE (crow/butterfly): see p. 56.
Set up programmable mixes (ex: FLAP-ELEVATOR): see p. 60.
View additional setups on the internet: www.futaba-rc.com\faq\faq-9c.html.
(ACRO)
(GLID)
•Range(GLID): The range that mixing does not work near neutral of an elevator stick can be set up.
Hold the stick to the desired point (upper or lower side) , then press DIAL and hold one second to set the range.
