15
one second; the same method applies for aileron and elevator servos.
Never turn off the CGY760R while the GX (gyro) LED is blinking
green at high speed (about 5 / sec).
*If you turn off the power while high-speed blinking, setting changes can not be saved
and data errors may occur.
Governor operating precautions:
Governor
When the throttle servo is connected to the CGY760R, the battery
failsafe function within the CGY760R must be setup and enabled.
Throttle fail safe function (transmitter setting): Use the fail safe func-
tion for the channel that turns the governor on and off to set the fail
safe position to the point at which the governor is turned off. With this
setting, when the system enters the fail safe state, the governor will be
turned off, and the receiver throttle signal (fail safe position preset) will
be output directly.
When using the condition hold function on the transmitter, always
set the throttle servo maximum operating point to less than the point
at which the governor is activated. If this is not done the governor
may activate while in condition hold.
While preparing for flight or starting the engine, always ensure the
throttle remains below the governor activation point and do not select
any flight modes that may activate the governor.
If you prefer to activate the governor while the model is still on the
ground, always ensure that you have at least -1 degrees of pitch in the
model before activating the governor. This negative pitch is neces-
sary to prevent an unexpected lift off as the governor activates and the
head speed increases to the desired RPM.
Be sure to set the autorotation condition to the OFF side with the
governor ON / OFF switch function.
Periodically check the RPM sensor output to ensure proper gover-
