52
F
LT.
T
UNE
M
ENU
(
FLIGHT TUNING SETTING
)
)OLJKWWXQHVHWVFRQWURORIKHOLFRSWHUUROODLOHURQDQGSLWFKHOHYDWRUD[LV5HIHUWR
SDJHDQGGLVSOD\WKH
"
)/7781(
"
screen from the
"
%$6,&0(18
"
VFUHHQ
FLT. TUNE screen 1/3
From 3/3
From the "HP.Auth." of
FLT. Tune screen 3/3
(1) Base. Gain: Gyro base gain setting
This sets the Cyclic Gyro Base Gain. If the Rotor Head Gain (Rot HD Gn)
Channels are set to "INH" within the CGY760R "SBUS.BASIC" menu,
then the remote transmitter gain adjustment is not available. Thus the ac
-
tual working gain for the cyclic gyros is set by using the [
/
+] or [
/
-] key
within this parameter.
Set to 100, a transmitter Gain value of 100% will display 100% on the
GPB-1. If a pilot is in need of more gain, base gain can be increased to
allow the gain on the CGY760R to be higher than 100%.
Note: If using a 6CH or less "Base Gain" is equivalent to the rotor head
gain and can be adjusted manually on the gyro instead of via the trans-
mitter.
Setting ranges: 0 ~ 150% Initial value: 100%
(2) CYC. Rt: Cyclic rate setting
Cyclic rate sets the maximum Cyclic rate sets the maximum roll and flip
rate (d/s) as limited by the model’s ability to reach that set rate. Flip and
roll rates are set together with this single parameter. The cyclic rate is set
by using the [
/
+] or [
/
-] key.
Setting ranges: 10 ~ 500d/s Initial value: 300d/s
Go to 2/3 from any
cursor position
Cond
: :
:
To Next Page
