FutureLogic PSA-66-ST - Page 28

UM-STO-C Revision C 28
Operators and Technicians
Manual
PSA-66-001N
PSA
-
66
-
ST
General Specifications
PRINT MODES Printer languages TCL page description language
Subset of ESCP2 printer language
Page mode Full page mode printing (simultaneous 4 orientation
printing: 0º, 90º, 180º, 270º)
Line and box draw printer resident
OTHER Bitmap Graphics
PCX printer resident (stored in Flash) graphics
Line and box draw printer resident
INTERFACE Bi-Directional RS232C, full handshaking set
Netplex
PHYSICAL CHARACTERISTICS Dimensions 114mm W x 286mm D x 68mm H
Weight 7 lbs
ENVIRONMENTAL Operating temperature -5ºC to 50ºC
Storage temperature -20ºC to 85ºC
Operating humidity 5 to 95% RH
RELIABILITY Maintenance No user maintenance required
Printer completely removable with quick release bar
Print Head Life 50km minimum (320,000 tickets)
