UM-STO-C Revision C 10
Operators and Technicians
PSA-66-001N
2.4 Bezel Operation
The front bezel display allows the operator to determine the state of the printer on the casino floor, at a
distance, without disturbing the game. The table below lists the various conditions which the bezel
indicates.
Table 2-1 Bezel Display Status
Bezel Display Status
Solid On Printer Idle and Ready
Slow Blink Paper low or Printer Error
Fast Blink Ticket Printing and/or Ticket in chute
Off Printer power off
2.5 Keypad LED Operation and Printer Status Conditions
The keypad LEDs provide a more detailed reporting of system status. Table 2-2 below lists the status of
the keypad LEDs in a variety of status which are defined following.
Table 2-2 Keypad LEDs Status Reporting
CONDITION STATUS_LED
ERR_LED
Unit in Powered Off 0FF 0FF
Unit Ready ON OFF
Unit Flushed ON ON
Paper out OFF ON
Head Up OFF ON
Temperature Error OFF MED BLINK
Voltage Error OFF SLOW BLINK
Print Head Error ON FAST BLINK
Missing Black Index Mark ON FAST BLINK
Paper Jam ON FAST BLINK
Although there are a variety of error conditions which can occur, most printer errors are a result of the
printer running out of paper or the operator raising the head up lever. This section lists the possible error
which can occur, and how the condition is remedied.
PAPER OUT: This condition results when the printer detects that paper is not present. The printer scans
for a paper out condition at all times. Remedy the condition by loading a new paper stack.
HEAD UP: This condition results from lowering the head release lever. To remedy the error, it is
necessary to raise the blue lever on the side of the unit.
