6 APPENDIX A – General Specifications
Table 6-1 General Specifications
General Specifications
PRINTER Dimensions 114mm width x 286mm depth x 68mm height*
Weight 7 lbs
Power requirements 24VDC @ 2.0A avg. (4.0A peak with 60% gaming ticket)
Print head life 50km (320,000 tickets)
*Using US currency size ticket
PRINTING Method Direct thermal, top coated, fan-folded and perforated
Thickness 4.5 mil, 1 color/ 2 colors
Width (mm) 62mm
Storage 200, 400, 600, 800 and 1000 tickets depending on ticket tray
Ticket trays Interchangeable. 200, 400, 600, 1000 ticket tray with quick
release bar
SPECIFICATIONS Print Speed 75mm/second (3 inches per second)
Complete Print and Present 2.2 seconds
Print Resolution 8 dots / mm (203 dpi)
Application completely in-circuit re-programmable (via Flash)
Self test Yes
Bezel Control Two high current lighting control ports
PAPER Loading Automatic hands free
Paper feed Manual
Width 66mm (dollar bill size)
Length 156mm (dollar bill size)
Sensors Paper low sensor
Paper out sensor
Printer drawer open sensor
Ticket taken sensor
Ticket jam sensor
Ticket in chute sensor
Black Mark sensor
Host controllable buzzer
CHARACTERISTICS Fonts 4 (5.5 cpi, 7.5 cpi, 10 cpi, 20 cpi)
Font Scale-ability May be independently scaled from 1x –
7x in both height and
width
Barcodes Interleaved 2 of 5, Code 39, UPC-A, UPC-E, UPC-E+2,
UPC-E+5, Codabar, EAN-13, EAN-8, Code 128, MSI
Data buffer 8K
Memory 256K Flash & 128K Ram
Bezel Control 2 high current Ticket Printing bezel control ports

