4. Operating System and Equipment
Engine Tachometer
The engine tachometer is used to indicate the
current engine speed, in x1,000 r/min.
Hint
6000~8000r/min is the high load range of
engine. The engine shall not reach this range.
Otherwise, the engine is extremely easy to
damage.
Instrument cluster display
The display information includes: travel
information =>Refer to Page 44, menu setting
information =>Refer to Page 45, navigation
information* =>Refer to Page 47, audio and
entertainment information* =>Refer to Page 49,
and alarm message =>Refer to Page 46.
Caution
In case of abnormal display of the instrument
cluster display, for the sake of safety, stop the
vehicle immediately, and
contact an authorized
GAC Motor's dealer for maintenance.
Engine c
oolant temperature gauge
Engine coolant temperature gauge (i.e., water
temperature gauge) used for indicating the current
engine coolant temperature.
– The indication range is C ~ H, in which, "C"
represents low temperature and "H" indicates
high temperature.
– After the engine is started, an appropriate
number of bars of the coolant temperature
gauge come on depending on the temperature.
In normal cases, the bars come on to the
middle. When all the bars come on, the
current engine coolant temperature is too high.
Fuel gauge
Fuel gauge is used to indicate the current fuel
remaining in the tank.
– The indicating the range of E~F, in which, "E"
represents the fuel tank is empty, and "F"
represents the fuel tank is full. An appropriate
number of sections are illuminated depending
on the residual fuel.
– No bar or only the 1st bar coming on indicates
insufficient fuel in the fuel tank. The yellow
indicator light on the instrument cluster
flickers with alarm message, telling the driver
to refuel.
Gear Information*
– The current gear information is displayed
according to the received signal P, R, N or D.
Driving Mode Information*
– The current driving mode of the vehicle is
displayed according to the received signal.
Trip
– Display range: 0 km~9999.9km. – When the
trip is greater than 9999.9km, it will be reset
and then continue to accumulate.
– The trip may be reset through "Trip" in the
settings of instrument cluster menu.
Odometer– Display range: 0 km~999999 km.
Speedometer
Speedometer is used for indicating the current
vehicle speed, in km/h.
Caution
In order to drive safely, please strictly abide by
traffic rules. Do not overspeed at will.
