GALaxy eHydro Elevator Controller Section 6 – Main CPU Faults & Detailed Faults
6-97
Table 6-3: Faults from the COP Board Devices on the CTCAN Serial Port
Fault
Description
Possible Cause/Suggested Fix
LED Open Blue
Car Call Board LED open blue
• Faulty LED signal from RGB Board. Look at detailed
car faults log to determine device. 'dev' gives you
address for global CAN device, 'dv2' gives you local
CAN device and 'pf1' the number for the IO location
within the local board.
LED Open Grn
Car Call Board LED open
green
• Faulty LED signal from RGB Board. Look at detailed
car faults log to determine device. 'dev' gives you
address for global CAN device, 'dv2' gives you local
CAN device and 'pf1' the number for the IO location
within the local board.
LED Open Red
Car Call Board LED open red
• Faulty LED signal from RGB Board. Look at detailed
car faults log to determine device. 'dev' gives you
address for global CAN device, 'dv2' gives you local
CAN device and 'pf1' the number for the IO location
within the local board.
LED Short Red
Car Call Board LED short red
• Faulty LED signal from RGB Board. Look at detailed
car faults log to determine device. 'dev' gives you
address for global CAN device, dv2' gives you local
CAN device and 'pf1' the number for the IO location
within the local board.
LED Shrt Blue
Car Call Board LED short blue
• Faulty LED signal from RGB Board. Look at detailed
car faults log to determine device. 'dev' gives you
address for global CAN device, 'dv2' gives you local
CAN device and 'pf1' the number for the IO location
within the local board.
LED Sht Green
Car Call Board LED short
green
• Faulty LED signal from RGB Board. Look at detailed
car faults log to determine device. 'dev' gives you
address for global CAN device, 'dv2' gives you local
CAN device and 'pf1' the number for the IO location
within the local board.
