GALaxy eHydro Elevator Controller Section 6 – Main CPU Faults & Detailed Faults
6-103
DSF (dsf): Door Status Flags
Bit 0: (preDO) Pre-open Door Flag
Bit 4: (rdsUP) Rear Door Open Sequence Up Pilot
Bit 1: (dsUP) Door Open Sequence Up Pilot
Bit 5: (rdsDP) Rear Door Open Sequence Dn Pilot
Bit 2: (dsDP) Door Open Sequence Down Pilot
Bit 6: (rdsNP) Rear Door Open Sequence No Pilot
Bit 3: (dsNP) Door Open Sequence No Pilot
Bit 7:
STO: Next Stop Floor – Floor Number of next stop
INS: Inspection Status Flag (Status bit set to “1” when switch is on)
Bit 0: (INS) Car Top Inspection
Bit 1: (MRIN) Machine Room Inspection
Bit 2: (ACC) Access
Bit 3: (ICI) In Car Inspection
Bit 4: (LBP) Lock Bypass
Bit 5: (GBP) Gate Bypass
Bit 6: (AUTI) Not in Automatic (AUTO==0)
NDS: Next Car Up Door Sequence
0 = Initiate Next Up Door Open
1 = Opening Next Up Door
2 = Door full open on Next Up
3 = Allow door close for onward call
4 = Allow door close while on next up
DEV: Device Number
DV2: Device 2 Number
PF1: Program Flag 1
PF2: Program Flag 2
STATUSF: Control Status Flag (Status bit set to “1” when status active)
Bit 0: (sfS10) NO S10 power
Bit 17:
Bit 1: (sfHC) NO HC power
Bit 18:
Bit 2: (sfSS) NO SS input
Bit 19:
Bit 3:
Bit 20:
Bit 4:
Bit 21: (sfSHD) Shutdown (too many run attempts
Bit 5: (sfIO) I/O error during redundancy check
with faults)
Bit 6: (sfINS) Inspection or lock bypass fault
Bit 22: (sfAST) Annual Safety Test
Bit 7: (sfBPI) Binary Position Input Error
Bit 23: (sfSAF) Waiting for Safe (Door Locks and
Bit 8: (sfPOS) Position Error
Gate)
Bit 9: (sfAD) No automatic Doors
Bit 24: (sfTLM) UT or DT limit error
Bit 10: (sfSTP) Stop switch open
Bit 25:
Bit 11: (sfDZ) Door Zone fault
Bit 26: (sfDZF) UL, DL and DZ off at floor
Bit 12: (sfGDL) Gate or Door lock fault
Bit 27:
Bit 13:
Bit 28: (sfFST) Fire Fighter Stop Switch
Bit 14: (sfDCL) No DCL
Bit 29: (sfSEL) Selector Can error
Bit 15: (sfDCC) No Door Close Contact
Bit 30: (sfUDL) UL or DL fault
Bit 16:
Bit 31: (sfLEV) Leveling fault
