GALaxy eHydro Elevator Controller Section 6 – Main CPU Faults & Detailed Faults
6-102
EQU: Earthquake Flag
0 = Not on Earthquake Operation
1 = Earthquake Sensor Activated
2 = Counterweight Derailment Sensor
Activated
3 = Recover Away from the Counterweight
4 = Stopped at a Floor
FIR: Fire Flag
0 = Not on Fire Service
1 = Phase 1 Main Egress Return
2 = Phase 1 Alternate Egress Return
3 = Phase 1 Completed
4 = Phase 2 Door Hold
5 = Phase 2 Constant Pressure Door Open
6 = Phase 2 Constant Pressure Door Close
7 = Phase 2 Door Hold
8 = Phase 2 Momentary DCB Door Close
RFI: Rear Fire Flag
0 = Not on Fire Service
1 = Phase 1 Main Rear Egress Return
2 = Phase 1 Alternate Rear Egress Return
3 = Phase 1 Completed
4 = Phase 2 Rear Door Hold
5 = Phase 2 Constant Pressure Rear Door Open
6 = Phase 2 Constant Pressure Rear Door Close
7 = Phase 2 Rear Door Hold
8 = Phase 2 Momentary DCB Rear Door Close
HSF: High Speed Flag
STF: Start Flag
0 = No High Speed
1 = High Speed
0 = Not valid Start
1 = Start of Run
CAL: Direction of Calls
0 = No Call
1 = Above Call
2 = Below Call
3 = Above and Below Calls
ESP: Emergency Stop Flag
NST: Need to Stop Flag
1 = Emergency Stop
1 = Car need to stop at next floor
RLV: Re-level Flag
STE: Step Flag
1 = Car in re-leveling
1 = Step to the next position (non-distance
feedback)
