GALaxy eHydro Elevator Controller Section 6 – Main CPU Faults & Detailed Faults
6-105
STATUSF4: Control Status Flag (Status bit set to “1” when status active)
Bit 0:
Bit 16:
Bit 1:
Bit 17:
Bit 2:
Bit 18:
Bit 3:
Bit 19:
Bit 4:
Bit 20:
Bit 5:
Bit 21:
Bit 6:
Bit 22:
Bit 7:
Bit 23:
Bit 8:
Bit 24:
Bit 9:
Bit 25:
Bit 10:
Bit 26:
Bit 11:
Bit 27:
Bit 12:
Bit 28:
Bit 13:
Bit 29:
Bit 14:
Bit 30:
Bit 15:
Bit 31:
DPP Count (DPC): Position counts in pulses
Floor Count (FPC) = Floor Count in pulses
Slowdown Count (SDC): Slowdown counts in pulses
Enc Vel: Velocity feedback from Encoder in fpm
Enc Dir: Encoder Direction 0=none, 1=up,2=down
Flt Bits 1 (FltB1): Faults Bits 1 (Byte 0)
Bit 0: (fHWLN) Hoistway Not Learned (1=fault)
Bit 4:
Bit 1: (fHWI) Hardware Init Fault (1=fault)
Bit 5:
Bit 2:
Bit 6:
Bit 3:
Bit 7:
Flt Bits 2 (FltB2): Fault Bits 2 (Byte 1)
Bit 0: (fCOPC) COP CAN COM error
Bit 4:
Bit 1: (fSPBC) NTS SPI COM error
Bit 5: (fSELC) APS Selector CAN COM error
Bit 2:
Bit 6:
Bit 3:
Bit 7:
