GALaxy eHydro Elevator Controller Section 6 – Main CPU Faults & Detailed Faults
6-106
Flt Bits 3 (FltB3): Fault Bits 3 (Byte 2)
Bit 0:
Bit 4:
Bit 1:
Bit 5:
Bit 2: (fMTOL) Door Motor Overload
Bit 6:
Bit 3:
Bit 7:
Flt Bits 4 (FltB4): Fault Bits 4 (Byte 3)
Bit 0:
Bit 4:
Bit 1:
Bit 5:
Bit 2:
Bit 6:
Bit 3:
Bit 7:
SS Status: Safety String Status
Bit 0: (ssGOV) Governor input open
Bit 8: (ssFFS) Fire Fighter Stop Switch
Bit 1:
Bit 9: (ssCST) Car Stop Switch
Bit 2:
Bit 10: (ssMRS) Machine Room Stop Switch
Bit 3:
Bit 11:
Bit 4: (ssHSS) Hoistway Safety
Bit 12: (ssEXT) Car Exit Switch open
Bit 5: (ssCTS) Car Top Stop switch open
Bit 13:
Bit 6: (ssCSS) Car Safety Switch open
Bit 14:
Bit 7:
Bit 15:
PWR Status: Power Status
Bit 0: (psHC) Hall call power loss
Bit 8:
Bit 1: (psHCL) Hall call light power loss
Bit 9:
Bit 2: (psCC) Car call power loss
Bit 10:
Bit 3: (psCCL) Car call light power loss
Bit 11:
Bit 4: (psLHC) Lobby Hall common power loss
Bit 12:
Bit 5: (psFEP) Fire/Emergency Power Loss
Bit 13:
Bit 6:
Bit 14:
Bit 7:
Bit 15:
