GALaxy eHydro Elevator Controller Section 6 – Main CPU Faults & Detailed Faults
6-107
Run Status: Control Run Status Flag (Status bit set to “1” when status active)
Bit 0: (rsRUN) Car is running
Bit 1: (rsDNR) Down run signal
Bit 2: (rsUP) Up run signal
Bit 3: (rsDL) Down door zone Limit
Bit 4: (rsUL) Up door zone limit
Bit 5: (rsDZ) Door Zone
Bit 6: (rsDLT) Door Lock Top
Bit 7: (rsDLM) Door Lock Middle
Bit 8: (rsDLB) Door Lock bottom
Bit 9: (rsGS) Gate Switch
Bit 10: (rsRLM) Rear Door Lock Middle
Bit 11: (rsRGS) Rear Gate Switch
Bit 12: (rsDOL) Door open limit (0=active)
Bit 13: (rsDCL) Door Close Limit (0=active)
Bit 14: (rDOLR) Rear door open limit (0=active)
Bit 15: (rDCLR) Rear door close limit (0=active)
Bit 16: (rsEE) Electric eye or Detector Edge
Bit 17: (rsSE) Safety Edge
Bit 18: (rsEER) Rear Electric eye or Detector edge
Bit 19: (rsSER) Rear Safety Edge
Bit 20: (rsHSF) High Speed Flag
Bit 21: (rsSTF) Start Flag
Bit 22: (rLSTF) Leveling Start Flag
Bit 23: (rsDZA) Door Zone OR'd
Bit 24: (rsDO) Door Open
Bit 25: (rsDC) Door Close
Bit 26: (rsDOR) Rear Door Open
Bit 27: (rsDCR) Rear Door Close
Bit 28: (rsUN) Up Normal Limit
Bit 29: (rsDN) Down Normal Limit
Bit 30:
Bit 31:
NTS Count: NTS Processor Position count in pulses
NTS Vel: NTS Processor Velocity in fpm
NTS Cmd: NTS Processor Command1
Bit 0: 1 = Mark Floor
Bit 4:
Bit 1: 1 = Bottom Floor
Bit 5: 1 = Clear Hoistway Table
Bit 2: 1 = Top Floor
Bit 6:
Bit 3: 1 = Enter HW Learn Mode
Bit 7: 1 = Reset Fault
NTS Cmd: NTS Processor Command2
Bit 0: 1 = NTS Test
Bit 4:
Bit 1: 1 = Automatic Door Disable
Bit 5: 1 = Reset tx/rx count
Bit 2:
Bit 6: 1 = Set NTS Down Slowdown
Bit 3:
Bit 7: 1 = Set NTS Up Slowdown
