GALaxy eHydro Elevator Controller Section 6 – Main CPU Faults & Detailed Faults
6-108
NTS Stat: NTS Processor Status1
Bit 0: (HWLrn) Hoistway Learn
Bit 4: NTS APS Selector OK
Bit 1: APS Can Fault
Bit 5:
Bit 2: (ClipF) DZ Clip Fault
Bit 6: NTS APS Setup Fault
Bit 3:
Bit 7:
NTS Stat: NTS Processor Status2
Bit 0: Direction Up
Bit 4: Velocity Fault
Bit 1: Direction Down
Bit 5:
Bit 2: Direction Fault
Bit 6: Setup/Test Jumper
Bit 3: Limit (EMSD) Fault
Bit 7: Rear Door Jumper
NTS Stat: NTS Processor Door Zone
Bit 0: (UL) Up Door Zone Limit
Bit 4: (DZ Clip) Door Zone Clip
Bit 1: (DZ) Door Zone
Bit 5:
Bit 2: (DZA) Door Zone Auxiliary
Bit 6:
Bit 3: (DL) Down Door Zone Limit
Bit 7:
NTS Stat: NTS Processor Limits
Bit 0: (UN) Up Normal Directional Limit
Bit 4: (DN) Down Normal Directional Limit
Bit 1: (UT) Up Terminal Slowdown Limit
Bit 5: (DT) Down Terminal Slowdown Limit
Bit 2:
Bit 6:
Bit 3: (DL) Down Door Zone Limit
Bit 7:
Nudg Flags (Nud): Door Nudging Flags
Bit 0: (ngUP) Nudging Closed with Up Pilot
Bit 1: (ngDP) Nudging Closed with Down Pilot
Bit 2: (ngNP) Nudging Closed with No Pilot
Bit 3:
Bit 4: (rngUP) Rear Nudging Closed with UP
Bit 5: (rngDP) Rear Nudging Closed with Down
Bit 6: (rngNP) Rear Nudging Closed with No Pilot
Bit 7:
Door Req (DRq): Door Request Flags
Bit 0: (doRQ) Front Door Open Request
Bit 1: (dbRQ) Front Door Open Button Request
Bit 2: (cdRQ) Front Car Call Door Open Request
Bit 3: (doEN) Front Door Open Enable
Bit 4: (rdoRQ) Rear Door Open Request
Bit 5: (rdbRQ) Rear Door Open Button Request
Bit 6: (rcdRQ) Rear Car Call Door Open Request
Bit 7: (rdoEN) Rear Door Open Enable
Call Flags (CFg): Onward Call Flags
Bit 0: (dcAB) Directional Call Above
Bit 1: (dcBL) Directional Call Below
Bit 2: (owcAB) Onward Call Above
Bit 3: (owcBL) Onward Call Below
Bit 4: (occAB) Onward Car Call Above
Bit 5: (occBL) Onward Car Call Below
Bit 6: (ohcAB) Onward Hall Call Above
Bit 7: (ohcBL) Onward Hall Call Below
