GALaxy eHydro Elevator Controller Section 6 – Main CPU Faults & Detailed Faults
6-109
CkRunS: Check Run Status State
0 = No Run Op
17 = Door Request
1 = HW Learn Flt
18 = Door Open
2 = PAL Fault
19 = Door Closing
3 = Comm Error
20 = PreTq NewPref
4 = IO Test
21 = DC No DO Seq
5 = Norm Stop Tmr
22 = UC No DO Seq
6 = ATT No DC CC
23 = LC No DO Seq
7 = ATT No UP/DN
24 = RDC No DO Seq
8 = ATT No DClose
25 = RUC No DO Seq
9 = No ATT UP
26 = Viscosity
10 = No ATT No DC
27 = Relevel Req
11 = CarSw No DC
28 = No Calls
12 = CarSw DC Hold
29 = Earthquake
13 = Man Door Time
30 = No DCl
14 = SafeTest Year
31 = No Rear DCL
15 = SafeTst Month
32 = No SAFE
16 = SafeTest Day
33 = Running
CkStS: Check Start Status State
0 = No Start Op
20 = SUF Fail Off
1 = CCF Off Up
21 = SUF On w/SU
2 = CPU UN Off
22 = Run Up
3 = FSTU Fail On
23 = CPU DN Off
4 = SPD Failed On
24 = FSTD Fail On
5 = MC Failed On
25 = RUND Fail On
6 = MC Failed Off
26 = RUND Fail Off
7 = SPD Fail Off
27 = CPU Out On Dn
8 = RUNU Fail On
28 = CCF On w/RunD
9 = RUNU Fail Off
29 = NTS Out On Dn
10 = CPU Out On Up
30 = NTS DN Off
11 = CCF On w/RunU
31 = SD Failed On
12 = NTS Out On Up
32 = CPU DT Off
12 = NTS UN Off
33 = NTS DT Off
14 = SU Failed On
34 = SDF Failed On
15 = CPU UT Off
35 = SD Failed Off
16 = NTS UT Off
36 = CCF On w/SD
17 = SUF Failed On
37 = SDF Fail Off
18 = SU Failed Off
38 = SDF On/W SD
19 = CCF On w/SU
39 = RUN Down
