GALaxy eHydro Elevator Controller Section 7 – Main CPU Adjustable Variables
7-46
Table 7-8: Color Lights
Field Variable
Min
Max
Initial
HCD Off Color
0
15
15
Select what color LED to illuminate on hall call
button when button is NOT pressed. Used only with
GAL serial hall button fixtures. 0 Based on
Parameters1 Red2 Orange 3 Yellow4 Chartreuse 5
Green6 Aquamarine 7 Cyan8 Azure 9 Blue 10 Violet11
Magenta 12 Rose13 Rose White 14 Warm White 15
Cool White
HCDn On Color
0
15
15
Hall Call Down On Light Color. Select what color to
illuminate On hall call button when button is pressed.
Used only with GAL serail hall button fixtures.
0 Based on Parameters
1 Red
2 Orange
3 Yellow
4 Chartreuse
5 Green
6 Aquamarine
7 Cyan
8 Azure
9 Blue
10 Violet
11 Magenta
12 Rose
13 Rose White
14 Warm White
15 Cool White
