GAL GALaxy eHydro - Page 237

GALaxy eHydro Elevator Controller Section 7 – Main CPU Adjustable Variables
7-52
Table 7-8: Color Lights
Field Variable
Min
Max
Initial
Vip On Color
0
15
0
Hall Call VIP Light On Color.0 Based on Parameters1
Red2 Orange 3 Yellow4 Chartreuse 5 Green6
Aquamarine 7 Cyan8 Azure 9 Blue 10 Violet11
Magenta 12 Rose13 Rose White 14 Warm White 15
Cool White
Table 7-9: System Options
Field Variable
Min
Max
Initial
AP SSID Nmb
1
9
1
Network SSID Number. 1-9 sets the number to be
appended to the SSID for AP WiFi cards
Auto Flt Dpy
0
1
0
Automatic Fault Display. Enable to automatically
display a fault on the LCD screen.
AutWifi Setup
0
1
1
Automatic WiFi Setup. Turns on option to have
controller automatically update wifi board for galileo
if connection is lost.
0 = Disable,
1 = Enable
CAN Baud Rate
0
1
0
CAN Baud Rate. Set to zero and do not change.
Special jobs uitilize a different baud rate for CAN Bus.
All devices need to be reconfigured for new rate. CAN
Baud Rate,
0=115.2K,
1=57.6K
