GALaxy eHydro Elevator Controller Section 7 – Main CPU Adjustable Variables
7-56
Table 7-9: System Options
Field Variable
Min
Max
Initial
Hall Lan Baud
0
6
0
Hall Lantern COM Baud Rate.
0 = 2400,
1 = 4800
2 = 9600
3 = 19.2K
4 = 38.4K
5 = 57.6K
6 = 115.2K bits per second.
Low Door Volt
0
600
198
Low Door Voltage. Settings for Line Voltage Monitor
Board. It sets the value of voltage for 'Door Low
Voltage Fault' to be triggered.
Low Line Volt
0
600
198
Low Line Voltage. Settings for Line Voltage Monitor
Board. It sets the value of voltage for a 'Low Line
Voltage Fault' to be triggered.
Password
0
9999
0
Password Code to modify and adjust field variables
Pword Tim-out
0
3200
300
Password Time-out. The amount of inactive time for
the LCD to lock out the field variables.
Safe Test Day
1
31
0
Safety Test Day.
SafeTest Year
2000
2999
0
Safety Test Year.
SafeTst Month
1
12
0
Safety Test Month.
