GALaxy eHydro Elevator Controller Section 7 – Main CPU Adjustable Variables
7-57
Table 7-10: NTS Processor Adjustable Variables
Field Variables
Min
Max
Initial
Can Baud Rate
0
1
0
CAN Baud Rate. Set to zero and do not change.
Special jobs uitilize a different baud rate for CAN Bus.
All devices need to be reconfigured for new rate. CAN
Baud Rate,
0 = 115.2K,
1 = 57.6K
Debug Mode
0
7
0
Debug Mode
Number Valid
Fl
2
Top
Floor
2
Number of Valid Floors.
Top Speed
0
1600
200
Top Speed or Contract Speed of the car.
UT Limit Dist
0
50
0
Up Terminal Limit Distance
DT Limit Dist
0
50
0
Down Terminal Limit Distance
Table 7-11: Velocity Slowdown Table
FPM
UN/DN *
UT/DT *
TSD
TLH
50
2" above top
floor and
below bottom
floor
5"
4"
4" above top
floor
75
9"
7"
100
12"
10"
150
21"
17"
200
30"
22"
