G&D DP-HR-CPU Installation And Operation Manual

Console module »DP-HR-CON-Fiber-DH«
Computer and console modules (DP-HR) · 166
Technical data
DP-HR-CON-FIBER-DH
Interfaces to console Video: 2 × DisplayPort
Keyboard and mouse signals 2 × PS/2 socket
3 × USB-A
Audio: 2 × 3.5 mm jack plug
Tradeswitch-LED: 1 × D-SUB 9 socket
Data transmission to
the counterpart
Interface: 1 × LC-Duplex socket
Transmission distance:  DP-HR-CON-Fiber-DH(M)
Max. 100 Meter (62,5μ/125μ),
Max. 200 Meter (50μ/125μ OM2)
Max. 400 Meter (50μ/125μ OM3)
 DP-HR-CON-Fiber-DH(S)
Max. 5.000 Meter (9μ/125μ OS1)
 DP-HR-CON-Fiber-DH(S+)
Max. 10.000 Meter (9μ/125μ OS1)
Video Format: DisplayPort (DP 1.1a)
Colour depth: 24 Bit
Video bandwidth: 25 to 300 MP/s (Channel 1)
25 to 165 MP/s (Channel 2)
Max. 330 MP/s (total)
Examplary resolutions: Channel 1:
 2048 × 2048 @ 60 Hz (2K×2K)
 2048 × 2160 @ 60 Hz
 2560 × 1600 @ 60 Hz
 3840 × 2160 @ 30 Hz (Ultra HD)
 4096 × 2160 @ 30 Hz (4K)
 1920 × 1080 (50 or 60 Hz)
 1440 × 576i (50 Hz)
 1440 × 480i (60 Hz)
Channel 2:
 1920 × 1200 @ 60 Hz
 1280 × 1024 @ 85 Hz
 1080p60 (Full HD)
 640 × 480 @ 60 Hz
 Further VESA and CTA standardised
resolutions possible within video
bandwidth/pixel rate and
horizontal/vertical frequency.
