G&D DP-HR-CPU Installation And Operation Manual

Computer module »DP-HR-CPU-DH-UC«
Computer and console modules (DP-HR) · 62
Connections to the matrix switches
Connecting the first matrix switch
Trans. 1: Connect this interface to a Dynamic Port (RJ45) of the first matrix switch.
Connecting the second matrix switch
Trans. 2: Connect this interface to a Dynamic Port (RJ45) of the second matrix switch.
Power supply
Power In: Insert the power pack’s connection cable to this interface.
IMPORTANT: Connect only one of the computer module’s Trans. interfaces for
each matrix switch!
NOTE: Only use category 5e (or better) twisted pair cables to connect the devices.
ADVICE: You can also connect the computer module directly to up to two compatible
console modules.
Power In
Service
Power
Trans. 1Trans. 2
