Page 8 of 35 Version 1.2 GTLE Operating Manual
6. Stairlift structure & operating options
6.1. Possible controls
1
Run command transmitter
DOWN button
Depending on the direction of the arrow, the stairlift
will go up or down.
2
Run command transmitter UP
button
3
Open platform
Depending on the direction of the arrow, the platform
is folded down or up.
4
Close platform
5
Emergency signal
Activates an emergency signal tone on the unit
6
Emergency stop button
After actuation, the stairlift stops. To unlock, the
button must be turned.
7
Key switch
The system can only be put into operation with the key
Table 1: List of controls
Figure
3: Remote control
Figure
4: Additional cable remote control for folding seat
Figure
1: Control on the lift
Figure
2: Fixed mounted external remote control
