Page 14 of 35 Version 1.2 GTLE Operating Manual
8.4. Moving the platform into the parking position
After leaving the platform, the following must be done at the respective external control point
Turn the key switch to the ON position.
Press the Close platform button (Figure 2, Pos.4) continuously:
1. Fold up the platform until the limit switch has been left to check whether there
is still someone on it.
2. Swinging down the safety barriers
3. Folding up the platform.
After the movement has been completed, turn the key switch to the OFF position
and remove the key.
In order to achieve the highest possible passage width for the stairs and to make
the upper track tube, which can also be used as a handrail, accessible, the lower
stopping point is used as a parking stopping point in most cases.
9. Functionality of the display
The GTLE is equipped with an intelligent control system as standard, which includes a display.
The capacitive display (Figure 5, Pos. 13) is a great help for service purposes and problem
solving. For the end user, it provides permanently relevant information.
When the lift is in the idle position, the screen saver is shown on the display. By pressing the
display, it is deactivated and the most important points are visible in the main overview (number
of journeys, current stopping point, active charge or battery status). If no more operations are
performed, it automatically switches back to screen saver mode.
If a fault occurs, it is displayed either as a pictogram or in plain text. Possible error messages
can be found under point 14.
