GANSER LIFTSYSTEME GTLE - Driving Onto the Platform; Travelling on the Stairlift

GTLE Operating Manual Version 1.2 Page 13 of 35
8.2. Driving onto the platform
On the stairlift system, the platform is opened electromechanically.
Operation is as follows:
Press the Open platform button (Figure 2, Pos.3) continuously:
1. The platform opens
2. The two barriers move to the respective set positions.
After completed movements, turn key switch to OFF position, remove key and drive or walk
onto the platform.
8.3. Travelling on the stairlift
Right arrow key (cf. Figure 1, Pos. 1)
Left stopping point: By pressing the button continuously, the safety
barriers are closed and the lift moves in the direction
of the arrow.
Right stopping point: By pressing the button continuously, the
respective barriers set for opening are opened.
Middle stopping point: When reaching a middle stopping point, the lift is
briefly stopped, if the button is released and pressed
again, the respective barriers are opened. Pressing
the button again closes the barriers and the lift ride
starts again.
Left arrow key (cf. Figure 1, Pos. 2)
Right stopping point: By pressing the button continuously, the safety
barriers are closed and the lift moves in the direction
of the arrow.
Left stopping point: By pressing the button continuously, the respective
barriers set for opening are opened.
Middle stopping point: When reaching a middle stopping point, the lift is
briefly stopped, if the button is released and pressed
again, the respective barriers are opened. Pressing
the button again closes the barriers and the lift ride
starts again.
However, if the button is never released, the lift will
automatically move on again without opening the
barriers.
When the movement is complete, release the button and leave the platform.
Hold on tightly to the handle at all times while driving to avoid falling off the
platform.
