GTLE Operating Manual Version 1.2 Page 11 of 35
7.2. Operation by means of remote control
Depending on the version, remote controls (cf. Figure 3) may be included in the scope of
delivery. Remote controls are designed in a practical size and can be carried on the body. With
the help of these remote controls, operators no longer have to rely on fixed external controls.
Please always keep the remote controls in a safe place or activate the key lock.
The following controls are located on the remote controls:
Run command transmitter UP button
Depending on the direction of the arrow, the
stairlift will go up or down.
2
Run command transmitter DOWN
button
Depending on the direction of the arrow, the
platform is folded down or up.
Table 4: External control operating options
7.2.1. Activating/deactivating key lock
In order to avoid accidental pressing of an operating button, a button lock can be activated on
the remote controls or, if desired, deactivated at any time.
The remote control works with 2 different setting options:
1 - Key lock activated
2 - Key lock deactivated
To find out which mode is currently active, proceed as follows:
Press “Open platform” (Figure 3, Pos. 3) and "Close platform" (Figure 3, Pos. 4)
simultaneously. After about 1 second, either a red or a green LED lights up:
• If the green LED lights up, it means that your remote control is NOT password-
protected.
• If, on the other hand, the red LED lights up, your remote control is protected by a
password.
Activating or deactivating the key lock
To change the mode from “with password” to “without password”, or vice versa, press “Open
platform”(Figure 3, Pos. 3) and “Close platform” (Figure 3, Pos. 4) simultaneously for at least
10 seconds.
Operation with the key lock deactivated: In this mode, it is sufficient to press the desired
key. To move the lift upwards, simply press “Arrow up” (Figure 3, Pos. 3) and the transport
begins.
Operation with the key lock activated: When in this mode, these steps must be followed to
give commands to the stairlift:
• Press any button the green LED lights up
• Press the “Arrow up” button the red LED lights up
• Press the “Arrow down” button the red LED switches off
• Press the “Arrow down” button the red LED lights up again
• Press the “Arrow down” button the red LED switches off again
If the password has been entered correctly, the green LED flashes and the user now has 20
seconds to operate the lift. If you do not press any button for 20 seconds, the remote control
will lock again.
