Gantner GAT NET.Lock 7000 User Manual

GAT NET.Lock 7000 System
Technical Data
www.gantner.com HB_GAT-NETLOCK7000--EN_30 37
6. TECHNICAL DATA
6.1 GAT NET.Lock 7000
Nominal voltage U
DC
: 5 V
Power supply: Via connection cable from the slave controller
Average power consumption: 60 mW
RFID frequency: 13.56 MHz
Retaining force: Min. 1,500 N
Force on inner side of the door: Max. 100 N
User guidance: Multi-colour status LED
Interface: One-wire (special cable for supply, data and RF signal)
Number of locks per slave controller: 24
Connectors: MOLEX, type Micro-Fit 3.0™
Housing material: Plastic (PC)
Door width: Min. 230 mm
Dimensions: 110 x 100 x 25 mm
Permitted ambient temperature: 0 to +60 °C
Protection type: IP 52
Protection class: III
Weight: Approx. 160 g
Environment class based on VDS 2110: II (conditions in indoor areas)
6.2 GAT NET.Controller S 7000
Nominal voltage U
DC
: 24 V
Power supply unit: External power supply units (use only power supply units approved by GANT-
NER Electronic GmbH for the GAT NET.Controller 7000)
Average power consumption: -
Reader types
- GAT NET.Controller S 7000 F/ISO: MIFARE™ + ISO 15693
- GAT NET.Controller S 7000 B: LEGIC
®
(Advant)
Number of locks per slave controller: 24
GAT Lock Network: Max. 8 slave controllers GAT NET.Controller S 7000 at one master con-
troller GAT NET.Controller M 7000
Interface to the locks: 1 Wire (special cable for supply and data signal)
Interface between slave and master: RS 485
Connectors: - Slave to master (RS 485): RJ 45
- Locks: MOLEX, type Micro-Fit 3.0™
- Supply: MOLEX
Housing material: Plastic (ABS)
Dimensions: 310 x 133 x 42 mm (12.2 x 5.24 x 1.65 inch)
Permitted ambient temperature: 0 to +60 °C
Protection type: IP 40
Protection class: I
Weight: Approx. 600 g
Environment class based on VDS 2110: II (conditions in indoor areas)
