If the COM port (DB9 socket) on the master PC is oc-cupied, a RS232/USB
must be integrated.
PC - master device
RS232 to USB adapter
6.3 Installation of base covers
The base covers are packaged on the pallet separately when the system is
delivered. They are only allowed to be attached once the system has been
erected and connected up in its final location.
Installation of the base covers
There are special mounting brackets on the covers to enable the fixation
of the covers to the adjustable feet.
There are recesses on the adjustable feet for mount-ing the covers.
