37-1-615 Page 16

9CDL SERIES, TOP INLET, MAIN ROTOR DRIVE

MODEL WT. A

(inches)

OUTLINE

DIMENSIONS

DRAWING NO.

9CDL13R 1475 38.56 5 24.16 32.04 301CBP800

9CDL18R 1680 43.56 6.50 29.16 37.04 302CBP800

9CDL23R 1905 48.56 11.50 34.16 42.04 303CBP800

MODEL E – INLET F – DISCHARGE

9CDL13R

8.00 FLANGE, 13.5 O.D., 8 HOLES

.75 – 10 UNC TAP, 11.75 DIA. B.C.

8.00 FLANGE, 13.5 O.D., 8 HOLES

.75 – 10 UNC TAP, 11.75 DIA. B.C.

9CDL18R

10.00 FLANGE, 16 O.D., 12 HOLES

.875 – 9 UNC TAP, 14.25 DIA. B.C.

8.00 FLANGE, 13.5 O.D., 8 HOLES

.75 – 10 UNC TAP, 11.75 DIA. B.C.

9CDL23R

10.00 FLANGE, 16 O.D., 12 HOLES

.875 – 9 UNC TAP, 14.25 DIA. B.C.

8.00 FLANGE, 13.5 O.D., 8 HOLES

.75 – 10 UNC TAP, 11.75 DIA. B.C.

FIGURE 2-5 – OUTLINE DIMENSIONS (CONTINUED)

Maintain Blower Reliability and Performance2
Foreword3
Table of Contents4
Index5
List of Illustrations6
Safety Precautions7
Introduction Your Key to Trouble Free Service8
Section 1 Equipment Check8
Section 2 Installation9
Figure 2-1 - Operating Principle9
Figure 2-2 - Accessories and Safety Devices10
Figure 2-3 - Belt Drive Overhung Load Calculations13
Figure 2-4 - Outline Dimensions16
Figure 2-5 - Outline Dimensions (Continued)17
Section 3 Operation18
Figure 3-1 - Maximum Rating18
Figure 3-2 - Water Quality Requirements19
Figure 3-3 - Liquid Rate20
Figure 3-4- Inlet Water Injection Diagram20
Figure 3-5 - Altitude - Pressure/Vacuum21
Figure 3-6 - Minimum Speed, Maximum Pressure or Vacuum22
Section 4 Maintenance24
Figure 4-1 - Aeon Pd Synthetic Lubricant24
Figure 4-2 - Synthetic Lubricant Chart25
Figure 4-3 - Non-Synthetic Lubricant Chart25
Figure 4-4 - Oil Bath Filter27
Figure 4-5 - Oil Wetted Filter-Silencer27
Figure 4-6 - Dry Type Filter and Filter-Silencer28
Section 5 Parts List30
Section 6 Disassembly Instructions34
Figure 6-1 - Adaptor Plate34
Figure 6-2 - Adaptor Plate34
Figure 6-3- Spanner Wrench34
Figure 6-4 - Adaptor Plates34
Figure 6-5 - Puller35
Figure 6-6 - Alternate Adaptor Plates35
Figure 6-7 - Carrier Flange36
Figure 6-8 - Bearing Clamp Plate Shim36
Figure 6-9 - Puller36
Section 7 Assembly Instructions38
Figure 6-10 - Rotor Sling Removal38
Figure 6-11 - Jack Screws38
Figure 7-1 - Rotor Shaft Seals39
Figure 7-2 - Bearing Spacers39
Figure 7-3 - Discharge Opening39
Figure 7-4 - Lower the Gate Rotor into the Housing Assembly39
Figure 7-5 - Angular Contact Bearing Assembly40
Figure 7-6 - Bearing Installation40
Figure 7-7 - Discharge End Bearing Carrier41
Figure 7-8 - Rotor End Clearnace Chart (Unit Cold)41
Figure 7-9 - Depth Micrometer - Rotor Lobes41
Figure 7-10 - Outside Micrometer - Thickness of Shims41
Figure 7-11 - Discharge Opening & Dowel Pins42
Figure 7-12 - Dial Indicator42
Figure 7-13 - Seal Installation Guide43
Figure 7-14 - Protective Installation Sleeves over each Shaft43
Figure 7-15 - Micrometer - Thickness of Shaft Shim Set44
Figure 7-16 - Shaft Extention44
Figure 7-17 - Bearing Press Plates45
Figure 7-18 - Bearing Clamp Plates45
Figure 7-19 - Discharge Opening45
Figure 7-20 - Reinforcing Plate45
Figure 7-21 - End Cover Assembly46
Figure 7-22 - Bearing Bore47
Figure 7-23 - Depth Micrometer - Measure Distance to End of Bearing Spacer Assembly47
Figure 7-24 - Oil Seal on Gate Rotor Shaft Assembly47
Figure 7-25 - Slide Shims over the Shafts Assembly47
Figure 7-26 - Press Plate and Jack Screw Assembly48
Figure 7-27 - Install Hub & Pinion Pull Tight with Locking Device Assembly48
Figure 7-28 - Mount Indicator and Button Bracket Assembly48
Figure 7-29 - Smallest Minus Reading49
Figure 7-30 - Smallest Plus Reading49
Figure 7-31 - Setting the Interlobe Clearance49
Figure 7-32 - Hold Gear & Shaft from Turning Tighten Five Gear to Hub "Nylok" Screws49
Warranty51
