37-1-615 Page 32
OVERHAUL KIT -- 311CBP6010
Description Qty. Part Number
Installation Sleeve For Oil Seal ................................................................
1 303CBP074
Installation Sleeve For Oil Seal ................................................................
1 304CBT074
Installation Sleeve For Oil Seal ................................................................
1 305CBP074
Bearing Spacer........................................................................................
2 8500037
Bearing Spacer........................................................................................
2 8504506
Shaft Air Seal ..........................................................................................
2 8500390
Shaft Air Seal ..........................................................................................
2 8500389
Housing Shim ..........................................................................................
1 8502896
Housing Shim Set ....................................................................................
1 8502890
Shaft Shim Set ........................................................................................
2 8500257
Shaft Shim Set ........................................................................................
2 8500253
End Cover Gasket ...................................................................................
2 8502800
Shaft Oil Seal ..........................................................................................
1 307CBP199
* Bearing Oil Seal ......................................................................................
1 306CBT199
* Bearing Oil Seal......................................................................................
1 304CBP199
Ball Bearing (Angular Contact) ................................................................
2 8500410
Ball Bearing (Angular Contact) ................................................................
2 8500408
Roller Bearing (Cylindrical) .....................................................................
1 8501202
Roller Bearing (Cylindrical) .....................................................................
1 8501201
Bearing Lock Nut ....................................................................................
2 50Z15
Bearing Lock Nut ....................................................................................
1 50Z12
Bearing Lock Washer .............................................................................
2 95N15
Bearing Lock Washer .............................................................................
1 95N12
Screw – Socket Head Lock .....................................................................
4 75P12N
Screw – Socket Head Lock .....................................................................
16 75P6N
Screw – Socket Head Lock .....................................................................
5 75P2N
Screw – Socket Head Lock .....................................................................
3 75P77N
Timing Washer .......................................................................................
5 95W49
Seal Adaptor Gasket ..............................................................................
1 8500146
Screw – Socket Head Lock .....................................................................
3 75P73N
* Bearing Oil Seal .....................................................................................
1 300CBT199
* Bearing Oil Seal .....................................................................................
1 305CBP199
Parts List and Service Manual ................................................................
1 37-1-615
Shim Set – Bearing Retainer ..................................................................
1 300CBP732
IMPORTANT: For spare parts requirement in remote areas, export or where more than one unit is
operating, a spare gear set is recommended. For 9CDL Series, order Gear Kit part number
300CBP6008.
NOTE: Overhaul Kit is recommended for spare parts and/or scheduled maintenance or overhaul
requirements. The oil seal installation sleeves are reusable. The Overhaul Kit without the
installation sleeves is part number 310CBP6010.
