Gardner Denver AUTO SENTRY EAU99P - Figure 2-5 - Heat Exchanger Approximate Water Flow; Figure 2-6 - Aftercooler Approximate Water Flow

13-10-615 Page 19
HEAT EXCHANGER (INTERNATIONAL)
Water Temperature to Heat
Exchanger
(ls)
KW Model
16° C 21° C27° C 32° C
Maximum
Water Flow
(ls) *
Approximate Water
Pressure Drop @ 32° C
Water Temperature
(bar)
150 EAU99R & S 1.2 1.5 2.0 3.0 7.0
186 EAU99R & S 1.5 1.9 2.5 3.8 7.0
225 EAU99R & S 1.8 2.3 3.1 4.6 7.0
Less than .15 bar for any
flow rate shown in the
table
* Flows exceeding "Maximum Water Flow" will cause severe erosion and will void unit warranty.
Figure 2-5 – HEAT EXCHANGER APPROXIMATE WATER FLOW
AFTERCOOLER (DOMESTIC)
Water Temperature to Heat
Exchanger
(gpm)
HP Model
60° F 70° F 80° F 90° F
Maximum
Water Flow
(gpm) *
Approximate Water
Pressure Drop @ 90° F
Water Temperature
(psi)
200 EAU99P 3.0 3.7 5.0 7.5 110
250 EAU99P 3.8 4.8 6.4 9.5 110
300 EAU99P 4.6 5.8 7.7 11.6 110
Less than 1 psi for any flow
rate shown in the table
* Flows exceeding "Maximum Water Flow" will cause severe erosion and will void unit warranty.
AFTERCOOLER (INTERNATIONAL)
Water Temperature to Heat
Exchanger
(ls)
kw Model
16° C 21° C27° C 32° C
Maximum
Water Flow
(ls) *
Approximate Water
Pressure Drop @ 32° C
Water Temperature
(bar)
150 EAU99R & S 0.2 0.2 0.3 0.5 7.0
186 EAU99R & S 0.2 0.3 0.4 0.6 7.0
225 EAU99R & S 0.3 0.4 0.5 0.7 7.0
Less than .1 bar for any
flow rate shown in the table
* Flows exceeding "Maximum Water Flow" will cause severe erosion and will void unit warranty.
Figure 2-6 – AFTERCOOLER APPROXIMATE WATER FLOW
